VW 09K (Aisin TF-72SC) 6-Speed Automatic Transaxle (High Torque) · VW / Audi / Porsche · Expert rebuild service since 1987. Lifetime warranty. Free diagnostic.
2006–2016 VW Passat (2.0T FWD higher output), 2009–2017 VW Tiguan 2.0T, 2010–2018 Audi Q5 2.0T (FWD variant), 2010–2016 VW CC 2.0T
| Configuration | 6-speed automatic FWD transaxle (higher torque TF-72SC variant) |
|---|---|
| Gear Ratios | 1st 3.59:1 · 2nd 2.19:1 · 3rd 1.41:1 · 4th 1.00:1 · 5th 0.83:1 · 6th 0.64:1 · Rev 3.16:1 |
| Fluid Type | VW/Audi G 055 025 A2 ATF |
| Fluid Capacity | 8.2 qts total, 3.8 qts service refill |
The 09K sees the same TCC shudder as the 09G, but 2.0T turbocharged torque makes it more prevalent and earlier-occurring.
Symptoms: Vibration at 40–55 mph, DTC P0740, shudder reduces at WOT
SV-1 solenoid failure causes 1-2 shift quality issues — same failure mode as 09G.
Symptoms: DTC P0750, harsh 1-2 shift, transmission reluctant to upshift from 1st
2.0T turbo torque and AWD transfer loads in Tiguan accelerate clutch pack wear compared to standard 09G applications.
Symptoms: Slip under hard acceleration, DTC P0732 or P0734
09K rebuild replaces solenoid body, all clutch packs (upgraded frictions for 2.0T), torque converter, and all seals. VW G 055 025 A2 ATF used.
VW G 055 025 A2 ATF every 30,000 miles for turbocharged applications. Tiguan owners should also service the Haldex AWD unit separately every 40,000 miles.
The 09K (TF-72SC) is the higher-torque-rated version of the 09G (TF-60SN), designed for 2.0T turbo applications. Clutch capacity is larger.
VW Passat 2.0T FWD, Tiguan 2.0T, CC 2.0T, and Audi Q5 2.0T FWD from 2006–2018.
A full rebuild ranges $1,800–$2,300 at Chicago Transmission.
VW G 055 025 A2 ATF.
Yes — the Haldex AWD coupling uses separate fluid that must be serviced every 40,000 miles independently of the transmission fluid.
Free diagnostic, written estimate, lifetime warranty. Chicago's 09K (TF-72SC) rebuild specialists since 1987.
