ZF 5HP19 5-Speed Automatic Transmission (VW/Audi/Porsche Applications) · VW / Audi / Porsche · Expert rebuild service since 1987. Lifetime warranty. Free diagnostic.
1997–2005 Audi A4/A6/A8 (V6/V8 quattro), 1997–2004 VW Passat V6 (quattro AWD), 1997–2002 Porsche Boxster S, 1998–2001 Audi allroad quattro (early)
| Configuration | 5-speed automatic RWD/AWD longitudinal transmission (ZF platform, VW/Audi calibration) |
|---|---|
| Gear Ratios | 1st 3.67:1 · 2nd 2.00:1 · 3rd 1.41:1 · 4th 1.00:1 · 5th 0.74:1 · Rev 4.10:1 |
| Fluid Type | ZF LifeGuardFluid 5 / Audi ATF (G 055 025 A2 compatible) |
| Fluid Capacity | 8.5 qts total, 4.0 qts service refill |
VW/Audi-calibrated 5HP19 units have solenoid body wear that causes shift quality issues. The failure mode is similar to BMW applications but with different DTC codes due to VAG diagnostic systems.
Symptoms: DTC P0750–P0758 (VAG format), erratic shift quality, limp mode
TCC shudder from neglected ZF fluid is the same as in BMW 5HP19 applications — the ZF design is identical.
Symptoms: Vibration at 45–65 mph, DTC P0740, better with fresh ZF LGF5 fluid
Longitudinal quattro applications suffer from output shaft seal failure between transmission and rear diff.
Symptoms: ATF leak from output flange area, low ATF level, ATF contamination in driveshaft tunnel
5HP19 rebuild (VW/Audi) replaces solenoid body, all clutch packs, torque converter, output shaft seals, and all seals. ZF LifeGuardFluid 5 used. quattro transfer flange seal replaced.
ZF LifeGuardFluid 5 (or VW G 055 025 A2 equivalent) every 40,000 miles. quattro transfer case requires separate fluid service. Always use VW/Audi diagnostic equipment for VAG-calibrated 5HP19 units.
The hardware is identical — the ZF platform is shared. The calibration (shift points, pressure curves) differs per manufacturer, and diagnostic procedures use BMW ISTA vs. VAG-COM respectively.
A4/A6/A8 V6/V8 quattro, allroad quattro, and VW Passat V6 quattro from 1997–2005.
A full rebuild ranges $1,800–$2,400 at Chicago Transmission.
ZF LifeGuardFluid 5 or compatible Audi G 055 025 A2 ATF.
TCC shudder from degraded ZF fluid is the most common cause. Try a ZF LGF5 fluid flush before authorizing a rebuild.
Free diagnostic, written estimate, lifetime warranty. Chicago's ZF 5HP19 (VW/Audi) rebuild specialists since 1987.
