Mercedes-Benz 722.8 7-Speed Automatic Transaxle (7G-Tronic FWD/AWD) · Mercedes-Benz · Expert rebuild service since 1987. Lifetime warranty. Free diagnostic.
2012–2021 Mercedes-Benz B-Class (W246), 2012–2021 CLA-Class (C117), 2013–2021 GLA-Class (X156), 2015–2021 A-Class (W176)
| Configuration | 7-speed automatic FWD/4MATIC transaxle (dual-clutch variant) |
|---|---|
| Gear Ratios | 1st 4.38:1 · 2nd 2.86:1 · 3rd 1.92:1 · 4th 1.37:1 · 5th 1.00:1 · 6th 0.82:1 · 7th 0.73:1 · Rev 3.42:1 |
| Fluid Type | Mercedes-Benz ATF (MB 236.15) |
| Fluid Capacity | 7.5 qts total, 3.5 qts service refill |
The 722.8 uses wet multi-plate clutches (not a traditional torque converter). Fluid contamination or degradation causes clutch shudder and engagement problems.
Symptoms: Shudder on launch, harsh engagement from stop, DTC P0810 or P0840
The mechatronic unit fails as on RWD 7G-Tronic units, causing limp mode and erratic shifting.
Symptoms: Limp mode, DTC codes across P0750 range, harsh or absent upshifts
The integrated front differential bearings wear after high mileage, producing a whine under load.
Symptoms: Whining proportional to vehicle speed, vibration under acceleration, noise worse when loaded
722.8 rebuild replaces wet clutch sets, mechatronic unit, FWD differential bearing, and all seals. MB 236.15 fluid used. All solenoids replaced. Specialized tooling required for FWD architecture.
Mercedes-Benz MB 236.15 ATF every 40,000 miles. The wet-clutch architecture requires correct fluid — MB 236.15 is not interchangeable with MB 236.14 used in RWD 7G-Tronic units.
W246 B-Class, C117 CLA-Class, X156 GLA-Class, and W176 A-Class from 2012–2021.
No — the 722.8 is a FWD wet-clutch design sharing the 7-speed architecture. The internal construction and fluid specification differ from the RWD 722.7.
A full rebuild ranges $2,300–$3,000 at Chicago Transmission.
Mercedes-Benz MB 236.15 ATF — different from the MB 236.14 used in RWD Mercedes models.
Wet clutch contamination from degraded MB 236.15 fluid is the most common cause. Start with a fluid inspection and change.
