Honda BJGA 6-Speed Automatic Transaxle (AWD) · Honda / Acura · Expert rebuild service since 1987. Lifetime warranty. Free diagnostic.
2014–2020 Acura MDX AWD, 2016–2020 Acura RDX AWD, 2015–2017 Honda Pilot AWD
| Configuration | 6-speed automatic AWD transaxle |
|---|---|
| Gear Ratios | 1st 3.56:1 · 2nd 2.06:1 · 3rd 1.42:1 · 4th 1.00:1 · 5th 0.71:1 · 6th 0.57:1 · Rev 2.46:1 |
| Fluid Type | Honda ATF-DW1 (transmission), Honda DPS-F (rear diff) |
| Fluid Capacity | 9.0 qts trans total, 4.0 qts service refill; 0.9 qt rear diff |
BJGA TCC shudder is amplified by AWD drivetrain loads. The added torque transfer through the rear axle increases heat load on the TCC friction disc.
Symptoms: Shudder at 40–55 mph, more noticeable on AWD engagement, DTC P0740
The rear differential uses separate Honda DPS-F fluid. Neglecting this service causes rear differential bearing wear and eventually AWD system failure.
Symptoms: AWD warning light, rear differential whine, poor traction on slippery surfaces
One or more of the six shift solenoids develops electrical resistance out of spec, causing intermittent shift quality issues.
Symptoms: DTC P0750–P0775 range, random harsh or soft shifts, MIL on
BJGA rebuild replaces all clutch packs, torque converter (upgraded friction), and shift solenoid set. Rear differential is serviced with DPS-F fluid. All seals and bearings are renewed. AWD transfer unit is inspected and serviced.
Change ATF-DW1 every 30,000 miles and Honda DPS-F rear differential fluid every 30,000 miles — these are separate services. Never use the same fluid for both.
The BJGA is the AWD version of Honda's 6-speed automatic, used in Acura MDX/RDX and Honda Pilot AWD models.
Yes — the rear differential uses Honda DPS-F fluid which is different from the ATF-DW1 in the transmission. Both need separate service every 30,000 miles.
A full rebuild ranges $2,000–$2,550 at Chicago Transmission, including rear differential service.
FWD MDX models use the BJFA; SH-AWD and basic AWD MDX models use the BJGA.
Typically 2–3 business days at Chicago Transmission.
