Honda SLXA 5-Speed Automatic Transaxle · Honda / Acura · Expert rebuild service since 1987. Lifetime warranty. Free diagnostic.
2002–2011 Honda CR-V (2.4L), 2003–2011 Honda Element (4-cylinder)
| Configuration | 5-speed automatic FWD/AWD transaxle |
|---|---|
| Gear Ratios | 1st 2.76:1 · 2nd 1.55:1 · 3rd 1.03:1 · 4th 0.71:1 · 5th 0.56:1 · Rev 2.05:1 |
| Fluid Type | Honda ATF-Z1 (early), Honda ATF-DW1 (2008+) |
| Fluid Capacity | 7.0 qts total, 3.2 qts service refill |
The SLXA shares the same clutch pack undersize design that affects the broader Honda B-series/S-series family. CR-V AWD applications suffer higher rates due to load.
Symptoms: Slip or shudder on 2-3 upshift, DTC P0732, metal particles in ATF
The rear torque transfer clutch wears in AWD CR-V units, causing loss of AWD capability and a shudder on turns.
Symptoms: AWD warning light, shudder on turns, reduced traction in slippery conditions
CR-V owners that switch from Z1 to DW1 or use generic ATF create chemistry mismatches that accelerate clutch wear.
Symptoms: Shudder after fluid service, harsh shift feel, premature clutch pack wear
SLXA rebuild replaces all clutch packs with upgraded frictions. AWD units receive rear transfer clutch inspection and replacement. Valve body solenoids are replaced. Correct ATF (Z1 or DW1 by year) is used. Torque converter is rebuilt.
Use ATF-Z1 on pre-2008 CR-V and ATF-DW1 on 2008+ models — do not mix. Change every 30,000 miles. AWD units should also have the rear differential (DPS fluid) serviced simultaneously.
2002–2011 Honda CR-V and 2003–2011 Honda Element with automatic transmission.
Yes — pre-2008 CR-V uses ATF-Z1; 2008+ uses ATF-DW1. Check your door jamb sticker or owner's manual to confirm.
A full rebuild ranges $1,600–$2,100 at Chicago Transmission.
This is typically the AWD rear transfer clutch failing. It's separate from the main transmission and can be serviced independently in many cases.
A properly rebuilt SLXA with upgraded clutch packs typically lasts 150,000+ additional miles with regular fluid service.
Free diagnostic, written estimate, lifetime warranty. Chicago's SLXA rebuild specialists since 1987.
